DraftSight and SOLIDWORKS PDM: Getting Started

Article by Jerald Staley on Dec 10, 2020

What is the SOLIDWORKS PDM Add-in for DraftSight

The DraftSight for SOLIDWORKS PDM add-in is a connector for DraftSight Professional, Premium, and Enterprise. This add-in allows a user to perform file vault operations from within the DraftSight application. The add-in consists of a dropdown menu, two toolbars, and a status window that you can activate to carry out commands such as:

  • Check out and check in files and Xrefs to the file vault
  • Update title block properties
  • Access the file data card information
  • Get the latest versions or previous versions of files and Xrefs
  • Access PDM functions from the DraftSight command line

Of course, installing the add-in requires a license for one of these DraftSight editions. However, you can use DraftSight with SOLIDWORKS PDM Standard, Professional, or SOLIDWORKS Manage. There is also a role on the 3DEXPERIENCE Platform for integration with that as well. If you use any of those tools for data management, DraftSight has an add-in that makes integration seamless.

How to add SOLIDWORKS PDM into your DraftSight tool

The add-in is included with SOLIDWORKS PDM 2016 (Standard and Professional edition) or a later version client installation. The add-in registers automatically if DraftSight is present when installed. If DraftSight is installed on a system that already has a SOLIDWORKS PDM client installation, you might have to modify the client installation to add the DraftSight add-in.

Learn how to get PDM installed on your system in the video below.



Note:  When you set the Client Options make sure you check on the DraftSight add-in as in the image below.

Add SOLIDWORKS PDM to DraftSight

Once you have the PDM add-in and DraftSight both installed, you need to turn on the add-in within DraftSight. To activate the add-in from within DraftSight, go to Manage > Add-ins, and activate SOLIDWORKS PDM add-in.

DraftSight SOLIDWORKS PDM Add-in

If you are not seeing the Manage option in the ribbon bar, please note the workspace settings in the top right corner of your DraftSight application. You will need to be in the Drafting and Annotation workspace to see the Manage tab for the add-ins.

DraftSight Drafting and Annotation

With the PDM add-in turned on you will see the PDM tab added to the ribbon bar as well as the quick access menu in the top right corner of the interface.

Getting Started with DraftSight and SOLIDWORKS PDM Add-In

You are now ready to start using the power of SOLIDWORKS PDM with your DraftSight application.
