Stratasys F3300
Scale Up Your Manufacturing
Now Serving US & Canada
THE NEW STANDARD
The Stratasys F3300 3D Printer is the most efficient and productive FDM system to date. This advanced technology incorporates a range of new capabilities designed to optimize your 3D printing experience. Elevate your 3D printing game with the F3300 and experience unparalleled control and quality.
The Mystery
Stratasys F3300 Truth:
What They Don’t Want You to Know
Discover the truth about the Stratasys F3300 3D Printer and why its groundbreaking technology may have been kept under wraps. Could this innovation reshape the future—or was it intentionally hidden? Join GoEngineer's Tyler Reid as he investigates the conspiracy.
Lower COST PER PART:
- Increased print speeds
- Decreased material pricing
- High part yield
- Reduction in labor
DOUBLE the throughput
- Faster gantry speed
- Increased material extrusion rates
- Autocallibration
- Multiple extruders with patented automatic tool changer
INcreased Accuracy
- Redundant extruder system
- System health monitoring
- Integrated material dryers
- EtherCAT onboard system monitoring and communication
Features
Integrated Material Dryers
The F3300 is equipped with integrated material dryers, ensuring prints maintain top-notch mechanical properties. These onboard dryers combine dry air and temperature control to maintain ideal humidity levels, allowing you to set a precise drying prescription for optimal material desiccation.
Precise Gantry Controls
The F3300's gantry system, responsible for material deposition, features linear encoders renowned for their exceptional accuracy in positioning control. This translates to impeccable material application and flawless print outcomes.
Advanced Extruder Control
For production-grade applications that demand consistency and quality, the F3300's extruders offer advanced features and intelligent software algorithms. These features enable precise temperature control of plastic flow, resulting in highly accurate material application.
A Revolution in Design: Accelerating the Design Workflow
The design process can seem like a never-ending circle. Thanks to the speed and accuracy of 3D Printing, you can get to market faster than ever and achieve your business goals. In this paper, you will discover:
- How Brooks Running was able to thoroughly test during the iteration phase
- How 3D Printing is a cost-effective way to validate your project
- How to increase the speed of iterative productions
Is your process keeping you competitive? 3D printing transforms product design and development, making companies more competitive. Don’t fall behind. Read the white paper and learn how to leverage 3D printing to gain the edge on your competition.
F3300 MATERIALS
ASA
Acrylonitrile styrene acrylate
– New Standard material for all-purpose prototyping
– UV-stabilized for outdoor production parts
– Superior aesthetics and 10 color options
– All-around average mechanical performance
Potential applications:
– Conceptual models
– Functional prototypes
– Manufacturing tools
– Production parts
PC
Polycarbonate
– Material known for its superior strength and durability
– Stable material that will not change shape over time
– Available in a biocompatible version
• PC-ISO | ISO 10993 USP Class VI | F900 only
– Great material for use on the shop floor
Potential applications:
– Demanding prototypes
– Tooling & fixtures
– Metal bending patterns
– Composite patterns
– Medical production parts
ULTEM 9085
Polyetherimide
– Flame-retardant, high performing material
– High thermal & chemical resistance
– Flame, Smoke, and Toxicity rating
• 14 CFR/FAR 25.853 | ASTM F814/E662
– Fungus resistant
• MIL-STD-810G
– Available in general purpose or certified grade
• Raw & filament analysis | lot number traceability
Potential applications:
– Advanced functional prototypes
– Production parts
– Manufacturing tools and patterns
Nylon 12CF
Polyamide + Chopped Carbon Fiber
– Composite material with 35% chopped carbon fiber reinforcement
– Highest flexural strength and stiffness-to-weight ratio FDM material
– Moderate chemical resistance
– Static dissipative qualities
Potential applications:
– Metal component replacement
– Production parts
– Tooling
F3300 Specifications
Model Materials
- ASA
- PC
- ULTEM 9085
- FDM Nylon 12CF
Support Structure
- Soluble for most materials
- Break-away for ULTEM
Material Delivery
4 material spool bays feeding 4 extruders; mix-and-match model or support; independently controlled onboard material dryers included (120°C max temp)
Network Connectivity
10/100 Base T connection; Ethernet Protocol, RJ45 connector, IPv6
Layer thickness
- 0.007 in.
- 0.010 in.
- 0.020 in.
Net build size
600 x 600 x 800 mm (23.6 x 23.6 x 31.5 in.)
Power Requirements
208V, 3 PH, 30A dedicated circuit, 50/60 Hz, 5-wire (L-L-L-N-G)
Achievable Accuracy
+/- .067 mm or +/- .0015 mm per mm, whichever is greater
(+/- .0026 in. or +/-.0015 in. per in., whichever is greater).
Z part accuracy includes an additional tolerance of -0.000/+ slice height.
Regulatory Compliance
CE (Machinery Directive & EMC) 2006/42/EC, cTUVus, FCC Part B
System Size and weight
218.4 x 203.2 x 162.6 cm (86 x 80 x 64 in); 1360 kg (3000 lbs.).
With Manufacturing Light Tower: 236.2 x 203.2 x 162.6 cm (93 x 80 x 64 in.)
Software
GrabCAD Print
Professional 3D Printing Made Easy and Accessible
GrabCAD Print is the most complete solution for Stratasys 3D printers on the planet. The intuitive, easy-to-use software allows for simplified preparation, scheduling, monitoring, and reporting of print jobs. With the ability to read and understand CAD files natively, GrabCAD Print offers an efficient workflow that streamlines job management in shared office and model shop environments.
INSIGHT SOFTWARE
OPTIMIZE BUILD OUTPUT FOR 3D PRINTING
Insight software prepares your CAD program’s STL output for 3D manufacturing on a Fortus machine by automatically slicing and generating support structures and material extrusion paths. For maximum control, users can manually edit parameters that determine the look, strength, and precision of parts as well as the speed and material use of the FDM process.
- Optimize build orientation for maximum strength and smoothest surface finish
- Customize supports for fast, easy removal and best use of materials
- Program pauses into the build for any reason, such as to embed hardware or circuitry
- Manipulate tool paths for advanced control over part properties
Included with Insight is Control Center. This sophisticated software application communicates with user workstations and Fortus systems, to manage jobs and monitor production status. Design, engineering, and manufacturing teams can network and share 3D manufacturing capacity to maximize efficiency and throughput.
*Compatible with GrabCAD Print for use with job reports, scheduling, and remote monitoring.
Frequently Asked Questions
• Faster gantry speed which positions the extruders
• More effective extruders capable of faster filament extrusion
• Multiple extruders that enable faster material changeover and minimize heat-up and cool-down, reducing non-printing time
• Local Z-plane extruder movement which occurs faster than moving the heavier build platen
• Automatic, hands-off, labor-free calibration
depth 203.2 cm (80 in.); height 254.5 cm (100.2 in.).
